SECTION 2 DISASSEMBLY
r
The equipment can be removed using the following procedure. Switch board Set Case ASSY, microphone Translation board (ECM-330 only)
Note : Follow the disassembly procedure in the numerical order given.
2-1. CASE ASSY, MICROPHONE
5 Remove solder 2
Frame
1
Lead wire (Black)
4
Grip
3 Screw (+KTP 2x5)
Case ASSY, microphone
2-2. SWITCH BOARD
Cover (B)
5 Remove solder 2
Switch board
5 Remove solder
Black (ECM-360)/White (ECM-330) White (ECM-360 only) Orange
6 Spring, ground
White Black White Black Red
1 Claw
4
Red Black 1 Claw
Frame
1 Claws
3 Claws
�3�
|
