Installing and Connecting the TV
Connecting a VCR and Cable TV
Use this hookup if: � You have cable TV that does not require a cable box. Disconnect all power sources before making any connections.
1 2 3
Connect the CATV cable to the VCR�s IN jack. Using the supplied 75-ohm coaxial cable, connect the VCR�s OUT jack to the TV�s VHF/UHF jack. Using AUDIO and S VIDEO cables, connect the VCR�s AUDIO and S VIDEO OUT jacks to the TV�s AUDIO and S VIDEO IN jacks.
Rear of TV
75-ohm coaxial cable (supplied)
VHF/UHF R-AUDIO-L VIDEO S VIDEO R-AUDIO-L Y VIDEO 2 IN PB PR R L DC IN 16.5V VIDEO 1 IN AUDIO OUT
75-ohm coaxial cable (supplied)
AUDIO-R (red) AUDIO-L (white) VIDEO (yellow)
S VIDEO
VCR
Cable VMC-810S/820S (not supplied)
YC-15V/30V (not supplied)
Note
To watch the pictures input from the S VIDEO input jack, set �Auto YC� to �On� in the (Setup) menu (See below).
Tip
If your VCR is not equipped with S VIDEO, use a VIDEO cable (yellow) instead of the S VIDEO cable.
When connecting both VIDEO OUT and S VIDEO OUT You can select which jack the TV receives the input signal from on the menu screen. The TV is factory set to receive S VIDEO input signals.
1 2 3 4 5
Press TV/VIDEO repeatedly to select VIDEO 1 IN. Press MENU. Press V/v to select (Setup), then press . . Press V/v to select �Auto YC,� then press
To watch the pictures input from the S VIDEO input jack: Press V/v to select �On,� then press . To watch the pictures input from the VIDEO input jack: Press V/v to select �Off,� then press .
