MZ-M100
Example of Calculation:
Result Item No. 0211 0212 0213 0214 0215 0216 Parameter Pr_nominal 2.48 mW Decimal 50 30 147 40 38 116 Hexadecimal 32h 1Eh 93h 28h 26h 74h
Kr �0.3 %/°C Pw_nominal 7.35 mW Kw �0.4 %/°C Prmin Pwmin 1.9 mW 5.8 mW
3-5-3. Other setting Procedure: 1. Enter the test mode (Display Check mode). 2. Press the [VOL+] key to enter the Manual mode. 3. Press the [VOL+] key once and press the > key five time to select the item number 1113 and display as follows.
Display of the remote commander
113 SS**$$##
adjustment value (hexadecimal)
Procedure: 1. Enter the test mode (Display Check mode). 2. Press the [VOL+] key to enter the Manual mode. 3. Press the > key once, press the [VOL+] key once, and press the > key once again to display as follows.
Display of the remote commander
210 DiscPr
4. Press the > key once to select the item number 0211. 5. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of LCD becomes calculated value. 6. Press the X key on the set or � key on the remote commander to write the adjusted value. 7. Press the > key to next item. 8. Repeat adjustment from step 4 until item number 0216. 3-5-2. Destination setting Procedure: 1. Enter the test mode (Display Check mode). 2. Press the [VOL+] key to enter the Manual mode. 3. Press the > key five time to select the item number 0113 and display as follows.
Display of the remote commander
113 DistFL **
adjustment value (hexadecimal)
4. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of �**� on the LCD becomes �1A�. 5. Press the X key on the set or � key on the remote commander to write the adjusted value. ($$ blinks and disc mark rotates on the LCD) 6. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of �$$�on the LCD becomes �20�. 7. Press the X key on the set or � key on the remote commander to write the adjusted value. (## blinks and disc mark rotates on the LCD) 8. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of �##�on the LCD becomes �94�. 9. Press the X key on the set or � key on the remote commander to write the adjusted value. 10. Press the [VOL+] key once to change the adjustment value of �**� on the LCD into �1B�. 11. Press the X key on the set or � key on the remote commander to write the adjusted value. ($$ blinks and disc mark rotates on the LCD) 12. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of �$$�on the LCD becomes �F1�. 13. Press the X key on the set or � key on the remote commander to write the adjusted value. (## blinks and disc mark rotates on the LCD) 14. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of �##�on the LCD becomes �1A�. 15. Press the X key on the set or � key on the remote commander to write the adjusted value. 16. Press the x key four times and back to the Display Check mode.
4. Press the [VOL+]/[VOL--] key and set the adjustment value of �**� on the LCD becomes �20�. 5. Press the X key on the set or � key on the remote commander to write the adjusted value. 6. Press the > key to select the item number 0114. 7. Press the [VOL+]/[VOL--] key and set the adjustment value of the LCD becomes �80�. 8. Press the X key on the set or � key on the remote commander to write the adjusted value. 9. Press the x key four times and back to the Display Check mode.
