TX-SR502_En.book Page 48 Friday, March 12, 2004 1:05 PM

Advanced Setup
Crossover Frequency

Advanced setup cannot be set while headphones are connected, Speaker B is on, or the multi channel input is being used.

4

To get the best bass performance from your speaker system, you need to set the crossover frequency according to the size and frequency response of your subwoofer and other speakers (front, center, and surround).

Press the [SETUP] button. Setup closes.

1

AMP

Press the [AMP] button followed by the [SETUP] button on the remote controller.

Note: � For a more accurate setting, look up the frequency response in the manuals supplied with your speakers and set accordingly. In addition, listen to some music that you know well and choose a higher crossover frequency if you think there�s not enough sound coming from the subwoofer; a lower setting if you think there�s too much.

2
ENTER

Use the Up and Down [ ]/[ ] buttons to select �1. SP Con�g,� and then press the [ENTER] button.

Speaker Distance
To get the best from surround sound, it�s important that the sound from each speaker reaches the listener at the same time. To achieve this, you need to specify the distance from each speaker to the listening position.

ENTER

1
Use the Down [ ] button to select �Crossover,� and then use the Left and Right [ ]/[ ] buttons to select a crossover frequency. Choose a crossover frequency suitable for your setup. If you�re using a subwoofer, choose a crossover frequency based on the diameter of your front speakers. If you�re not using a subwoofer, use the diameter of the �rst speaker that you speci�ed as Small in steps 4 through 7 in the �Speaker con�guration� setting.
Speaker cone diameter Over 8 in. (20 cm) 6-1/2 to 8 in. (16�20 cm) 5-1/4 to 6-1/2 in. (13�16 cm) 3-1/2 to 5-1/4 in. (9�13 cm) Under 3-1/2 in. (9 cm) Crossover frequency 60Hz 80Hz
DISPLAY

Measure and make a note of the distance from each speaker to the listening position.
AMP

3
ENTER

2

Press the [AMP] button followed by the [SETUP] button on the remote controller.

ENTER

3
ENTER

Use the Up and Down [ ]/[ ] buttons to select �2. SP Distance,� and then press the [ENTER] button.

ENTER

4

Use the [DISPLAY] button to switch ft or m. ft: distances in feet. Can be set from 1 to 30 feet in 1-foot steps. m: distances in meters. Can be set from 0.3 to 9 meters in 0.3-meter steps.

100Hz (default) 120Hz 150Hz

48
